Product Overview
Lub 22kW AC EV Charger yog peb -theem hluav taws xob tsheb muab khoom siv ua haujlwm rau cov chaw nres tsheb ua lag luam, cov chaw nres tsheb, thiab cov chaw nyob ntau- cov chaw nyob. Nws xa mus txog 32A txuas ntxiv tam sim no ntawm 400V AC, txhawb hom 3 them ib qho IEC 61851 tus qauv. Chav tsev muaj peev xwm ua kom muaj peev xwm sib npaug thiab sib txuas lus ntawm OCPP 1.6J / 2.0.1 rau seamless integration nrog backend tswj systems.
Cov ntsiab lus tseem ceeb
|
Parameter |
Specification |
|
Rated Input Voltage |
400V AC ± 15% (3-theem + N + PE) |
|
Input zaus |
50Hz / 60Hz |
|
Max tso zis zog |
22 kWm |
|
Rated Output Tam sim no |
32A Max rau ib theem |
|
Kev them nyiaj yug interface |
Hom 2 Cable / Hom 2 Qhov (IEC 62196-2) |
|
Metering raug |
Chav Kawm 1.0 (MID tau ntawv pov thawj xaiv tau) |
|
Kev sib txuas lus Interface |
Ethernet, Wi-Fi, 4G Cellular (yeem) |
|
Network Protocols |
OCPP 1.6J (Hloov mus rau OCPP 2.0.1 txhawb nqa) |
|
Kev tiv thaiv Ingress |
IP55 (Wallbox) / IP65 (Pedestal sib dhos) |
|
Impact Resistance |
IK 10 |
|
Ua haujlwm kub |
-30℃rau +55 degree |
|
Kev khiav dej num |
5% mus rau 95% tsis yog -condensing |
|
Txoj kev txias |
Ntuj Convection |
|
Dimensions (H x W x D) |
420mm x 300mm x 110mm |
|
Qhov hnyav |
Kwv yees li . 9.5 kg (Unit nkaus xwb) |
Cov yam ntxwv tseem ceeb ntawm cov khoom
Khoom siv hauv tsev:Polycarbonate thiab ASA alloy vaj tse, UV-stabilized, nplaim taws retardant rau UL94 V-0.
Kev tiv thaiv hluav taws xob:Integrated tshaj-voltage, nyob rau hauv-voltage, overload, luv-circuit, av txhaum, thiab tshaj- tiv thaiv kub.
Residual Current Detection:Ua-nyob rau hauv 6mA DC residual tam sim no nrhiav pom (RDC-DD) ua ke nrog Hom A RCD lossis Hom B RCD muab.
User Authentication:RFID nyeem ntawv (ISO/IEC 14443 A/B), ISO 15118 Plug & Charge npaj, thiab daim ntawv thov mobile ntawm OCPP backend.
Kev taw qhia txog xwm txheej:Multi-xim LED xwm txheej qhia bar (Standby, Charging, Fault, Network status).
System Architecture & Hardware Cheebtsam
Core Controller:Industrial-qib ARM-raws li microprocessor tswj kev nyab xeeb loops thiab them lub xeev lub tshuab.
Fais fab faib:Integrated contactor switching thiab metering module ib theem.
Mounting Options:Phab ntsa-mounted bracket standard; pem teb - sawv pedestal muaj raws li ib tug accessory.
Cable Management:Optional cable retractor lossis holster nuv rau Hom 2 tethered configurations.
Daim ntawv thov
Chaw nres tsheb ua lag luam:Chaw ua haujlwm chaw nres tsheb, chaw muag khoom, thiab chaw tos txais them nyiaj.
Fleet Depots:Lub nkoj xa khoom, cov neeg caij tsheb thauj neeg, thiab tsheb pabcuam hauv nroog.
Public Infrastructure:Txoj kev hauv nroog-sab them thiab them nyiaj-rau- siv chaw nres tsheb.
Chaw nyob Complexes:Cov tsev apartment yuav tsum muaj ntau- neeg siv kev tswj xyuas thiab kev sau nqi sib cais.
Compatibility & Kev koom ua ke
Tsheb Compatibility:Ua raws li txhua Lub Tsheb Hluav Taws Xob Hluav Taws Xob (BEVs) thiab Plug-hauv Hybrid Electric Vehicles (PHEVs) siv hom 2 inlets raws li IEC 62196.
Backend Integration:Tau tshaj txhua tus qauv OCPP 1.6J/2.0.1 Central Management System (CMS), ua rau thib peb -kev them nqi, kev tswj hwm tus nqi, thiab kev kuaj mob nyob deb.
Kev Tswj Xyuas Zog:Txhawb cov ntsuas ntse sab nraud thiab lub tsev / lub tsev tswj hwm lub zog (HEMS / BEMS) ntawm Modbus TCP / IP rau lub zog hluav taws xob capping.
Muab & Customization Options
Kev Pabcuam OEM / ODM:Kev cai lub npe, logo txhob lo lo ntxhuav- kev tshuaj ntsuam, kev cai pem hauv ntej vaj huam sib luag xim schemes, thiab localized firmware configurations.
Packing Specifications:Muaj export- qib thawv ntim nrog EPE ua npuas ncauj molding; palletized rau thawv shipping (kwv yees . 120 units ib txheej txheem pallet).
Yam tsawg kawg nkaus Order Quantity (MOQ):Hu rau kev muag khoom rau qib MOQ qhov pib hais txog kev kho vajtse thiab software branding.
Zoo / Kev Xeem
Factory xeem:100%.
Cov ntawv pov thawj:Raws li CE, IEC / EN 61851-1, IEC / EN 61851-21-2, RoHS raws.
Traceability:Tus naj npawb ntawm tus kheej tau muab rau txhua lub tsev rau cov khoom siv - qib kev tsim khoom thiab kev xeem - qhov tshwm sim nrhiav.
FAQ
Q: Puas yog lub charger no txhawb nqa kev sib npaug ntawm ntau lub tsev?
A: Yog. Ntau lub chargers tuaj yeem sib txuas lus hauv zos Ethernet lossis Wi-Fi kom sib faib cov peev txheej ruaj khov siv cov txheej txheem tswj hwm hauv zos.
Q: Puas yog RFID nyeem ntawv siv tau nrog daim npav Mifare txheem?
A: Yog lawm, kev sib xyaw RFID nyeem ntawv txhawb ISO / IEC 14443 A / B phaib ua haujlwm ntawm 13.56 MHz.
Q: Lub sij hawm ua ntej rau kev txiav txim ntau npaum li cas?
A: Lub sij hawm ua tus txheej txheem yog 15 mus rau 25 hnub ua haujlwm tom qab tau txais kev pom zoo thiab daim ntawv tso nyiaj tso nyiaj, nyob ntawm qhov kev txiav txim ntim.
Q: Lub sijhawm them cable puas tuaj yeem hloov kho?
A: Yog, tus qauv tethered cable ntev yog 5 meters, nrog rau 7-meter kev xaiv muaj raws li qhov kev thov.
